ABB XVC770BE101 3BHE021083R0101​ Video and Vision Control Module with High-Speed Data Interface

Core Functions & Technical Specifications

Functionality

• Real-Time Image Processing: Supports up to 12MP resolution at 60fps for high-precision defect detection in assembly processes .
• Multi-Camera Integration: Connects up to 8 industrial cameras (GigE Vision, USB3 Vision) for 360° monitoring of production lines .
• AI-Based Vision Algorithms: Pre-installed with machine learning models for pattern recognition, barcode reading, and part alignment .
• High-Speed Data Transmission: 3BHE021083R0101 provides 10Gbps Ethernet and PCIe 4.0 interfaces for low-latency communication with PLCs and edge servers .

Technical Specifications

Key Features

1. Advanced Vision Capabilities:
• Integrates stereo vision for 3D depth mapping, enabling precise measurement of component heights and gaps .
• Supports multi-spectral imaging (visible, IR, UV) for material classification and surface defect analysis .
2. Modular Architecture:
• XVC770BE101 can be daisy-chained with up to 4 modules for multi-zone inspection in large production lines .
• 3BHE021083R0101 allows hot-swappable expansion of I/O modules (e.g., analog inputs for sensor integration) .
3. Industrial-Grade Reliability:
• Built-in EMC shielding to withstand electromagnetic interference in factory environments .
• Redundant power inputs and watchdog timers for fail-safe operation in critical applications .
4. Seamless System Integration:
• Compatible with ABB’s IRC5 robot controllers and PLCnext Technology for real-time motion-vision coordination .
• Supports OPC UA and MQTT protocols for IIoT connectivity and cloud-based analytics .
