ABB 3BHB003387R0101 5SXE05-0151 5SHX08F4502 IGCT MODEL

Core Component: 3BHB003387R0101 (Drive Control Module)

- Product Type: Original ABB digital input + IGCT gate drive control board, belonging to the 3BHB series core industrial control cards.

- Core Specifications: Supports multi-channel power output, compact structure (approx. 120×100×60mm), weight 1.2kg, protection level suitable for industrial environments.

- Core Advantages: Fast response speed, strong anti-interference ability, signal isolation protection design, DIN rail mounting for easy installation, direct docking with

5SHX08F4502 module (plug-and-play).

- Core Functions: Collects on-site sensor and switch signals, outputs precise drive commands, and feeds back module operating status to the main control system to achieve

closed-loop control.

Core Component: 5SHX08F4502 (Power Execution Module)

- Product Type: High-performance IGCT (Integrated Gate-Commutated Thyristor) module, which can be used as a thyristor control unit or power converter module in some

scenarios.

- Core Specifications: Rated voltage 450V~4500V (adapting to different working conditions), rated current 8A~50A, maximum switching frequency up to 50kHz, operating

temperature range -55℃~150℃, protection level IP30.

- Core Advantages: Adopts advanced semiconductor technology, low power consumption, excellent heat dissipation, integrated overload, overvoltage and overheating

protection functions, long mechanical life, and drawer-type structure for easy maintenance.

- Core Functions: Realizes precise on-off control of high-voltage and large-current as well as power conversion, provides stable power output for industrial equipment, and

ensures safe and efficient operation of the system.

Combined Application & Product Attributes

- Matching Relationship: Factory-standard compatible combination, drive control and power execution work collaboratively, indispensable for each other.

- Application Fields: Power energy (wind power, photovoltaic, power grid stabilization equipment), industrial manufacturing (metallurgy, petrochemical, production line control),

transportation (railway traction systems), automation control (robots, monitoring systems), etc.

- Product Attributes: Original ABB genuine product, compliant with CE/ROHS certifications, 1-year warranty, industrial packaging, mainly used for equipment maintenance

replacement and system integration.
