ABB 3BHB003387R0101 GVC703AE01 3BHL00386P0101 5SHX0660F0001 IGCT

ABB 3BHB003387R0101 GVC703AE01 3BHL00386P0101 5SHX0660F0001 IGCT integrated gate commutation thyristor module.

1. Functional positioning: Designed specifically for high voltage, megawatt level applications, used to achieve high-power electrical energy conversion and control

   High voltage frequency converter: drives large motors (such as pumps and fans in mining, metallurgy, and petrochemical industries).

   Power transmission: High Voltage Direct Current (HVDC), Static Var Compensator (SVC).

   In the field of new energy: wind power inverters, inverters for energy storage systems.

2. Technical characteristics

   Electrical parameters:

    Maximum voltage: 845 VDC

   Continuous current: 1150 A

   Surge current: 45 kA

   Switching frequency: 2 kHz

   Design advantages:

3. Integrated gate driver: Built in driver circuit, simplifies system design and reduces costs.

   Compact structure: Approximately 120 × 100 × 60 mm in size, weighing 1.2 kg, suitable for high-density installation.

   Multiple protection: overvoltage, overcurrent, and overheating protection mechanisms ensure reliability under extreme working conditions.

   summarize

  3BHB003387R0101 is a high-voltage IGCT module used for megawatt level power conversion, with high reliability and compact design.
