ABB PFEA112-20 3BSE030369R0020 Precision Tension Electronic Control

ABB PFEA112-20 with part number 3BSE030369R0020 is a high-precision tension measuring and control electronic unit belonging to ABB Pressductor series.

It receives signals from two tension load cells, processes tension data with built-in high-speed algorithm, and outputs analog signals or transmits data via Profibus-DP

bus to upper PLC/DCS systems for closed-loop tension regulation. It is widely adopted as original replacement spare part for web tension control equipment maintenance in

winding and unwinding production lines.

Technical Specifications

Part Number: PFEA112-20 / 3BSE030369R0020

Manufacturer: ABB

Type: Tension Electronic Control Module

Sensor Input: 2 channels for ABB Pressductor tension load cell

Excitation Signal: 330 Hz, 0.5 A rms

Communication: Profibus-DP up to 12 Mbps

Analog Output: -5 ~ +11 VDC signal

Power Supply: 12–48 VDC (typical 24VDC)

Operating Temperature: -20°C ~ +50°C

Humidity: 5%–95% non-condensing

Protection Grade: IP20

Net Weight: Approx. 0.51 kg

Certification: CE, UL, RoHS

Origin: Switzerland

Key Features

Dual-channel tension sensor input design, supporting real-time tension collection for two measuring points.

Built-in multi-level adjustable filtering function to eliminate on-site vibration and electromagnetic interference.

Standard Profibus-DP communication interface for seamless data interaction with mainstream industrial control systems.

High measurement accuracy and fast response speed to guarantee stable tension control during high-speed production.

Compact DIN rail mounting structure, easy wiring, parameter setting and direct plug-and-play replacement.
