VIBRO-METER VM600 204-040-100-012 Module

The 204-040-100-012 (IOC4T) is a high-performance 4-channel vibration & displacement monitoring module for the VM600 machinery protection

and condition monitoring system, manufactured by VIBRO-METER (Spectris/Meggitt). It interfaces with IEPE/ICP accelerometers,

eddy-current displacement probes, and speed sensors, providing real-time vibration analysis, overspeed protection,

and alarm logic for critical rotating equipment (turbines, compressors, generators). Hot-swappable and fully compliant with API 670,

 it ensures continuous, reliable operation in harsh industrial environments.

3. Technical Specifications

Part Number: 204-040-100-012 (IOC4T)

Manufacturer: VIBRO-METER (Spectris Group, formerly Meggitt)

Series: VM600 System

Type: 4-Channel Vibration/Displacement Input Module

Channels: 4 isolated dynamic inputs

Sensor Compatibility:

IEPE/ICP accelerometer (2–20 mA constant current)

Eddy-current displacement probe (-24 VDC bias, -2 to -18 V output)

Speed probes (0–10 V pulse)

Input Ranges:

Acceleration: ±50 g

Displacement: 0–2 mm (pp)

Velocity: 0–50 mm/s

Sampling Rate: Up to 10 kHz/channel (synchronous)

Resolution: 24-bit ADC

Outputs:

4× Relay (SPDT, 5 A @ 250 VAC, alarm/danger configurable)

4× Analog (4–20 mA, vibration value/status)

Communication: RS-485 (Modbus RTU), VM600 backplane

Power: 24 VDC ±10% (rack-fed)

Operating Temp: -20°C to +70°C

Humidity: 5%–95% non-condensing

Dimensions: 6U × 20 mm × 125 mm (19” rack mount)

Weight: ~0.4 kg

Certifications: CE, UL, API 670, ISO 10816
