TRICONEX EPI3382 High-Performance EPI Communication Gateway Module for Tricon TMR Safety Controller

Product Description

EPI3382 is a dedicated external protocol communication module for Tricon/Tricon2 triple redundant safety systems, acting as data bridge between Triconex safety controllers and external

DCS, SCADA, HMI and historical databasesCSDN博.... Equipped with dual independent Ethernet ports, it supports Modbus TCP and multiple custom TCP/UDP protocols,

undertakes protocol conversion and data buffering to reduce main CPU load. Adopts full TMR synchronization design, supports redundant dual-module hot standby seamless switching,

isolated network circuit prevents external network interference from affecting safety logic. Widely used in petrochemical ESD, fire & gas safety cabinets as core maintenance spare part.

Technical Specifications

PN: EPI3382, Manufacturer: Triconex (Invensys), USA

System Compatibility: Tricon, Tricon2 TMR safety rack

Interfaces: 2×10/100Mbps Ethernet RJ45, system backplane bus

Supported Protocols: Modbus TCP, custom TCP/UDP

Power: 18–36VDC 24V nominal, max power 10W

Safety Grade: IEC61508 SIL3 certified

Mount: Standard rack plug-in, hot-swappable

Temp: -40℃ ~ +70℃ operation; -40℃ ~ +85℃ storage

Humidity: 5%–95% non-condensing, IP20 cabinet use

Dimension: 230×247×42mm, weight ~1.2kg

Indicators: Front LED for power, run, link, fault alarm

Key Features

Dual Ethernet redundant channels, automatic link switch without safety system interruption.

Independent communication processor offloads data tasks of Tricon main CPU.

Hardware electrical isolation between safety backplane and external industrial network.

TMR triple voting logic consistent with the whole safety system, single-point fault tolerant.

Hot-swap design, online replacement without stopping safety control system.

Rich self-diagnosis function to locate network disconnection, address conflict and communication timeout.

Wide-range DC power supply adapts unstable plant station power environment.

Rugged aluminum heat sink shell, anti-vibration and anti-electromagnetic interference.

Application Scope

ESD emergency shutdown system communication gateway for oil & gas, refinery and chemical plants

Fire & Gas detection safety control cabinet data exchange module

Thermal power plant boiler, turbine safety interlock Tricon system network expansion card

Offshore platform, LNG terminal safety instrument system (SIS) spare replacement

Interconnection between Triconex safety system and third-party DCS/SCADA/HMI

Global legacy Tricon safety cabinet overhaul, spare inventory and system upgrade projects
