EATON XVS-440-10MPI-1-1U XVS400 Series 10.4 Inch PROFIBUS MPI Integrated HMI/PLC Touch Operator Panel

Eaton XVS-440-10MPI-1-1U belongs to Eaton XVS400 Micro Panel high-end integrated human-machine interface product line, a 10.4-inch industrial touch screen with optional

onboard PLC runtime function. It serves as on-site central operation, data visualization and logic control terminal for complete machine automation equipment, realizing real-time display

of operating parameters, fault alarm pop-up, parameter setpoint modification, manual/automatic mode switching and equipment interlock logic execution.

This model is equipped with dedicated PROFIBUS MPI communication interface for direct high-speed data interaction with Siemens S7 series PLCs, meanwhile carrying Ethernet,

RS232 multi-channel communication ports to realize interconnection with variable frequency drives, remote I/O and third-party automation hosts. Adopting Windows CE embedded

operating system, it supports CF card program storage and project offline backup; aluminum alloy integrated housing with industrial anti-interference design adapts harsh workshop

production environment. It is a critical maintenance replacement spare part for packaging machinery, printing equipment, textile lines, CNC machine tools and legacy automation

system renovation projects worldwide.

Technical Specifications

Part Number: XVS-440-10MPI-1-1U

Manufacturer: Eaton (Moeller), Origin: Germany

Product Series: XVS400 Micro Panel Integrated HMI

Display Size: 10.4-inch TFT color LCD

Screen Resolution: VGA 640 × 480

Display Color: 256 / 65536 colors configurable

Brightness: 350 cd/m², software dimmable LED backlight

Touch Type: Infrared resistive touch panel

Onboard System: Windows CE embedded OS, CF card program storage

Processor: High-speed industrial embedded CPU

Communication Interfaces

PROFIBUS MPI dedicated port (match Siemens S7 PLC communication)

1× 10/100Mbps Ethernet RJ45

RS232 serial port, RS485 optional

Optional Function: Expandable onboard soft PLC runtime license

Power Supply: 24VDC auxiliary power supply

Installation Mode: Cabinet embedded panel mounting

Front Protection Grade: IP65, Rear housing IP20

Operating Temperature: 0℃ ~ +55℃

Storage Temperature: -20℃ ~ +70℃

Ambient Humidity: 5%–95% Non-Condensing

Backlight Lifespan: 50000 hours typical service life

Net Weight: Approx. 3.58kg

Compliance Certifications: CE, UL industrial safety certification

Key Features

Native PROFIBUS MPI communication design, seamless high-speed data exchange with Siemens S7-300/S7-400 PLC, convenient for original Siemens system matching replacement.

Integrated HMI + optional soft PLC all-in-one architecture, independent small logic control operation without external PLC, simplifying system configuration.

Multi-network communication layout (MPI + Ethernet + serial port), compatible with mainstream brands of inverters, servo drives and remote I/O modules for flexible networking.

Long-life adjustable LED backlight, stable display performance under long-term continuous production operation, reducing frequent screen fading failure.

Front panel IP65 dustproof and waterproof design, resistant to cutting fluid, dust and splash pollution in machine tool and workshop environment.

CF card project backup & clone function, fast program uploading/downloading during on-site maintenance, shortening equipment downtime.

Rich industrial graphic library, alarm logging, trend curve, recipe management and data recording functions, meeting complete machine monitoring and data traceability requirements.

Standard embedded opening size, pin-to-pin compatible with other XVS400 series models for direct plug-and-play replacement during equipment overhaul.
