RELIANCE 805405-1R-24451 SF3000 Single-Phase Field Power Excitation Module

Product Description

RELIANCE 805405-1R-24451 is a discontinued single-phase SCR field excitation power module under Reliance SF3000 AutoMax drive system, dedicated to supplying adjustable, current-stabilized excitation power for large DC shunt motors.

It works in tandem with three-phase armature power modules and shares the same PMI control rack. The internal four-SCR full-wave non-reversing bridge outputs regulated DC field voltage/current, controlled by AutoMax PLC logic to adjust motor field flux, realize speed weakening, constant torque and constant horsepower control.

Built-in isolated power cube, dv/dt surge suppression, internal AC fuses and inductive kickback clamping circuit to protect field windings and control board. Panel-mounted aluminum fin heat sink design, widely used as maintenance spare for metal rolling, paper mill, printing, extrusion DC drive control cabinets.

Suffix Explanation:

805405: Standard SF300 field power unit base model

1R: Hardware revision 1, 15A rated DC field output version

Technical Specifications

PN: 805405-1R, Manufacturer: Reliance Electric USA

Power Ratings

AC Input: 120–460 VAC single phase, 50/60Hz

DC Field Output: Max 15A continuous, up to 500 VDC

Rectifier: 4 SCR full-wave non-reversing bridge

Hardware & Interface

Communication: 18-pin ribbon cable connector to PMI rack control backplane

Mount: Cabinet panel flat mounting, large aluminum passive heat sink

Isolation: Full galvanic isolation between power stage and control logic

Internal Protection: AC input fuses, dv/dt RC absorption, inductive surge clamp, overcurrent hardware trip

Environmental

Operating Temp: -20℃ ~ +60℃; Storage -40℃ ~ +85℃

Humidity: 5%–95% non-condensing, IP20 cabinet grade

Weight: ~2.7kg (6 lbs shipping weight)

Compatible System: Reliance AutoMax PMI rack, SF3000 DC drive system

Configuration Software: AutoMax Programming Executive

Key Features

15A high-current field excitation output, matches large horsepower DC mill motors.

Closed-loop current regulation stabilizes field flux under grid voltage fluctuation.

Independent SCR power stage isolated from rack control logic, avoid power surge damaging main CPU.

Built-in inductive kickback clamping circuit eliminates field winding voltage spike during shutdown.

Wide 120–460V universal AC input, adapts different factory power distribution standards.

Standard panel mount fin heat sink, long-term stable continuous 24h heavy-load operation.

Matches full series AutoMax armature power modules for complete DC motor four-quadrant drive system.

Obsolete legacy spare, only surplus/refurbished units available for aging production line overhaul.

Application Scope

Metal steel rolling mill DC main motor field excitation regulator spare module

Paper & film winding, slitting line large DC unwinder/rewinder drive cabinet

Printing press, textile fiber stretching production line DC motor flux control unit

Extrusion, rubber calender heavy-duty DC drive PMI rack power module

Mining, port crane DC traction motor field power supply replacement

Global aging Reliance AutoMax SF3000 DC drive system maintenance and spare inventory backup
