KOLLMORGEN S72402-NANANA S700 High Performance Digital Servo Drive

Product Description

S72402-NANANA belongs to Kollmorgen S700 high-end servo amplifier series, made in USA. It is a 2.4kW single-axis servo drive with 24A continuous output current, compatible with synchronous, linear and asynchronous servo motors.

Equipped with built-in EtherCAT & CANopen industrial bus, standard STO safety torque off function. It supports resolver, incremental encoder and single-cable Hiperface DSL feedback. Integrated EMC filter and brake circuit, compact rack mounting design, widely used as replacement spare for packaging, printing, robotics and semiconductor automation equipment.

Technical Specifications

Model: S72402-NANANA, Brand: Kollmorgen, Origin: USA

Rated Power: 2.4kW, Peak Power: 4.8kW

Continuous Output Current: 24A RMS, Peak Current: 48A

Input Voltage: 3-phase 208–480VAC

Communication: EtherCAT, CANopen, RS232

Safety Function: STO Safe Torque Off (TÜV certified)

Supported Feedback: Resolver, Incremental Encoder, SFD3/Hiperface DSL

Switching Frequency: 8kHz

Operating Temp: 0℃ ~ +40℃, Humidity ≤85% non-condensing

Protection: Overvoltage, overcurrent, overheat, short circuit, motor stall

Mount: Cabinet DIN rack, IP20

Weight: 5.5kg

Key Features

24A high current output for high dynamic heavy-duty motion control.

Dual industrial bus EtherCAT/CANopen for fast real-time motion network.

Standard STO safety function to meet machinery safety standards.

Multi-type universal motor feedback interface, wide motor compatibility.

Auto motor identification & cogging suppression for smooth low-speed operation.

MMC memory card slot for one-click parameter backup and duplication.

Complete multi-layer fault protection to safeguard drive and servo motor.

Rugged metal housing with integrated cooling fan for long-term 24/7 operation.
