Rexroth DKC02.3-100-7-FW EcoDrive03 High-Performance Single-Axis Servo Drive Controller

Product Description

DKC02.3-100-7-FW belongs to Rexroth Indramat EcoDrive03 DKC series, a heavy-duty high-current digital servo amplifier manufactured in GermanyIndramat U....

It adopts advanced DSP closed-loop control architecture to realize precise position, speed and torque regulation for high-power 3-phase AC synchronous servo motors. The model features 100A continuous output current with 700V nominal DC bus voltage, suitable for heavy-load CNC machine tools, automotive automation lines, large printing and metal forming equipment.

The "-7-FW" suffix stands for SERCOS fiber optic real-time communication interface with complete firmware support. It supports mainstream encoder feedback including EnDat, resolver and incremental encoders, with built-in full-range fault diagnosis and multi-layer electrical protection circuits. Standard cabinet vertical mounting design, IP20 protection, conformal coated PCB for anti-vibration and anti-humidity, widely used as core maintenance spare for multi-axis high-power motion control systems.

Technical Specifications

Model: DKC02.3-100-7-FW, Part Code: R911279430

Brand: Bosch Rexroth Indramat, Origin: Germany

Input Power: 3-phase 200–480VAC, 50/60Hz

DC Bus Nominal Voltage: 700VDC, Max Output Voltage 800V

Output Current: Continuous 100A RMS, Peak 150A RMS

Switching Frequency: 4kHz / 8kHz configurable

Communication Interface: SERCOS fiber bus (7 interface variant), optional Profibus / EtherCAT expansion

Auxiliary Control Supply: 24VDC ±10%

Supported Feedback: EnDat 2.2, Resolver, Incremental Encoder

Dimensions: H360 × W105 × D261 mm

Net Weight: 9.7kg

Protection Class: IP20 (cabinet installation only)

Operating Temp: 0℃ ~ +45℃ full load; up to 55℃ with derated load

Humidity: 5%–95% non-condensing, conformal coated circuit board

Certifications: CE, UL industrial safety compliance

Key Features

100A high continuous output current, matches high-torque heavy-duty servo motors for large machine tools and press equipment.

SERCOS fiber real-time bus ensures ultra-fast synchronous multi-axis motion control with strong anti-interference.

Universal multi-type encoder feedback interface, compatible with all Rexroth Indramat servo motor series.

DSP high-speed closed-loop algorithm delivers ultra-smooth low-speed operation and rapid dynamic response.

Comprehensive protection: overvoltage, undervoltage, overcurrent, overheat, short circuit, motor stall and encoder failure alarm.

Front panel multi-color LED indicators for power, communication and fault status quick inspection.

Modular expandable design, supports external braking resistor modules for frequent deceleration heavy-load applications.

Rugged metal housing and industrial coated PCB, stable 24/7 continuous operation in high-vibration workshop environments.
