ABB PM864AK01 3BSE018161R1 AC800M Dual Ethernet CPU Controller

Product Description

PM864AK01 with code 3BSE018161R1 is standard CPU for ABB AC800M and System 800xA DCS, equipped with 32-bit RISC processor and 32MB memory.

It integrates dual 10/100Mbps Ethernet and RS232 port, supports Modbus TCP/RTU and mainstream industrial protocols. It realizes logic control, PID regulation and mass data collection, compatible with all S800 I/O modules. With conformal coated PCB and front fault indicators, it serves as common replacement spare for power, chemical and water treatment control racks.

Technical Specifications

Part No.: PM864AK01, Material Code: 3BSE018161R1

Brand: ABB, Origin: Switzerland

Processor: 32-bit RISC industrial CPU

Application Memory: 32MB

Max I/O Points: Up to 4000 mixed digital & analog signals

Communication Interfaces

2 × 10/100Mbps RJ45 Ethernet ports

RS232 service port for program download & diagnosis

Supported Protocols: Modbus TCP, Modbus RTU, Profibus DP, ABB native control protocol

Programming Standard: IEC 61131-3 (ST, LD, FBD, SFC)

Backplane Bus: CEX bus for AC800M I/O expansion

Power Supply: Supplied via rack backplane

Operating Temperature: 0℃ ~ +60℃ full load

Storage Temperature: -40℃ ~ +70℃

Humidity: 5%–95% non-condensing, conformal coated PCB

Protection Class: IP20 cabinet installation only

Mounting: Single slot plug-in with matching TP830 baseplate

Net Weight: Approx. 1.2kg

Certifications: CE, UL industrial compliance

Key Features

32MB large memory and high-speed RISC processor, stable for medium-scale multi-loop process control and data logging.

Dual independent Ethernet ports separate HMI, SCADA and field device communication to avoid single network breakdown.

Multi-protocol compatibility enables seamless connection with inverters, analyzers and third-party remote RTU systems.

RS232 local debug port supports firmware upgrade, parameter backup and offline fault analysis on site.

Front panel LED indicators display power, bus link and hardware fault status for quick troubleshooting.

Dedicated TP830 baseplate simplifies rack wiring and supports hot-swap under proper system configuration.

Full compatibility with all AC800M series I/O, communication and safety modules for flexible system expansion.

Anti-vibration conformal coated PCB, stable 24/7 continuous operation in dusty and humid industrial control rooms.
