Eaton XV-440-12TSB-1-10 12.1-inch Industrial TFT Touch HMI Panel

Product Description

XV-440-12TSB-1-10 belongs to Eaton XV400 series industrial touch screen for factory automation equipment monitoring.

It equips 12.1-inch color TFT display with infrared touch, built-in Ethernet, RS232/485, CAN and USB ports, supports Modbus TCP, CANopen and mainstream PLC communication protocols.

Front IP65 dustproof splash-proof, aluminum alloy frame, conformal coated PCB, cabinet embedded installation, common replacement spare for packaging, printing and machinery control cabinets.

Technical Specifications

Model: XV-440-12TSB-1-10, Brand: Eaton Moeller, Origin: Europe

Display: 12.1-inch TFT color LCD, infrared touch screen

Brightness: 250 cd/m² industrial grade backlight

Memory: 16MB SDRAM + 32MB Flash storage

Communication Interfaces

1 × RJ45 Ethernet port

RS232 / RS485 serial terminals

CAN bus interface for CANopen

USB host port for program upload/download

Power Supply: 24VDC industrial DC power input

Protection Grade: Front IP65, rear IP20

Operating Temperature: 0℃ ~ +60℃ full load

Storage Temperature: -20℃ ~ +70℃

Humidity: 5%–95% non-condensing, conformal coated PCB

Mounting: Cabinet door embedded installation

Net Weight: Approx. 1.5kg

Certifications: CE, UL industrial compliance

Key Features

12.1-inch large infrared touch screen supports glove operation, clear display under factory ambient light.

Rich multi-type communication ports connect Eaton PLC, inverters and third-party automation controllers.

Built-in CANopen bus interface realizes stable data transmission for distributed machine control systems.

Front IP65 waterproof and dustproof design resists workshop dust, water splash and coolant splashing.

USB local storage supports offline recipe storage, alarm history backup and program quick upgrade.

Aluminum alloy anti-corrosion front frame, compact embedded structure for easy on-site replacement.

Multiple industrial communication protocols compatible with most mainstream automation control equipment.

Anti-vibration conformal coated internal circuit, stable 24/7 continuous operation for production line equipment.
