ABB NBRA-669C Brake Chopper for 690V ACS800 Series Inverter

Product Description

NBRA-669C is a high-power braking chopper specially developed by ABB for 690V AC drive platform, perfectly matching ACS800 series R8 frame frequency converters. It consumes

regenerative energy generated by motors during rapid deceleration, lifting and lowering through external braking resistors, effectively avoiding DC bus overvoltage fault tripping of inverters.

The module adopts intelligent voltage threshold detection logic, automatically switching on the braking loop when the DC bus voltage exceeds the set value. Equipped with built-in overheat,

overcurrent and short-circuit protection, it outputs fault relay signals for upper system alarm interlock. It supports multi-module parallel expansion to meet large inertia load braking demands,

widely used as maintenance spare parts for port cranes, mine hoists, metallurgical rolling mills and heavy-duty conveyor equipment.

Technical Specifications

Model: NBRA-669C, Brand: ABB, Origin: Finland/Estonia

Rated Applicable Drive Voltage: 690V three-phase AC

Continuous Braking Power: 13.5kW

Peak Braking Power: 375kW (10–30s short-time duty)

Minimum External Brake Resistance: 2.7Ω, recommended 3×9Ω parallel connection

Control Power Supply: 24VDC

DC Bus Action Voltage: 720–800VDC adjustable, default 760VDC

Operating Temperature: -10℃ ~ +50℃ continuous operation

Storage Temperature: -40℃ ~ +70℃

Ambient Humidity: 5%–95% non-condensing environment

Protection Class: IP00 (must be installed inside sealed electrical cabinet)

Mounting: Screw fixed rear panel installation

Overall Dimension: 334mm(W) × 240mm(D) × 583.5mm(H)

Net Weight: Approx. 2.6kg

Certifications: CE, UL, industrial EMC anti-interference certification

Key Features

Professional 690V high-voltage grade design, exclusive matching ACS800 R8 frame large-power inverters.

Strong energy dissipation capacity, peak braking power up to 375kW, suitable for high-inertia frequent braking working conditions.

Precise DC voltage detection and fast chopping response, stable suppress overvoltage risk of drive system.

Complete multiple protection mechanisms including overheating, overcurrent and short circuit, effectively protect inverter main power unit.

Fault dry contact relay output, convenient for external alarm and safety interlock logic configuration.

Support multiple units parallel connection, flexible expand total braking power for heavy-load transformation projects.

Rugged industrial power module layout, strong anti-vibration and anti-interference ability for harsh workshop environment.

Standard ABB drive accessory, plug-and-play wiring, convenient for on-site replacement and equipment overhaul.
