ABB BC810K02 3BSE031155R1 DCS redundant bus communication module

Product Description

BC810K02 with material number 3BSE031155R1 is an official complete kit of ABB CEX-Bus bus segmentation and redundant interconnection unit, specially designed for ABB AC800M

controller and 800xA distributed control system platformABB.

The core function is to split the single CEX extended bus into multiple independent physical segments, isolate bus faults within a single segment and avoid the failure of one communication

expansion card leading to the collapse of the whole CEX bus network, greatly improving the overall availability of redundant communication architecture. It is used to expand the onboard

communication ports of PM series main controllers (PM861A/PM862/PM864A/PM865/PM866/PM867), support redundant PROFIBUS DP, Modbus TCP and other communication interface

modules access, realize seamless redundant switching of fieldbus links.

This complete set is a high-integrity hot-swap solution, supporting online CPU replacement and module live plugging without stopping the DCS control system. The kit includes 2pcs BC810 bus

interconnection main units, 2pcs TP857 mounting baseplates, 1m TK851 interconnection cable and 2pcs TB850 CEX-Bus terminal resistors. The circuit board adopts three-proof conformal coating,

standard DIN rail cabinet installation, widely used as key maintenance spare parts for thermal power units, petrochemical refining devices, offshore platforms, wind power and water treatment

800xA DCS system redundant communication transformation and overhaul projects.

Technical Specifications

Model: BC810K02, ABB Article No.: 3BSE031155R1

Brand: ABB, Origin: Sweden

Applicable Controller: AC800M PM861A, PM862, PM864A, PM865, PM866, PM866A, PM867 CPU modules

Core Role: CEX-Bus bus segment isolation, redundant communication interface expansion, bus fault isolation

Power Supply: 24VDC industrial DC power supply, allowable fluctuation ±15%

Power Consumption: Typical 1.2W, typical working current 50mA, maximum 70mAABB

Hot Swap Feature: Full support for online hot plug replacement of modules and main CPU

Operating Temperature: 0℃ ~ +55℃ continuous full-load operation

Storage Temperature: -40℃ ~ +70℃

Ambient Humidity: 5%–95% non-condensing environment, moisture-proof, mildew-proof and salt spray resistant coated circuit board

Protection Class: IP20 (only installed inside closed electrical control cabinet)

Installation Standard: EN60715 standard DIN rail fixed mounting via TP857 baseplate

Overall Dimension: 185mm(H) × 59mm(W) × 127.5mm(D)

Net Weight: Approx. 1.5kg per complete kit

Certifications: CE, UL61010 safety certification, ATEX II 3G Ex nA IIC T4 Gc Zone 2 hazardous area certification, EMC industrial anti-interference certification

Key Features

Physical segmentation of CEX extended bus, fault isolation of independent bus segments, single communication card or cable failure will not affect the operation of other bus branches,

fundamentally enhance DCS communication network fault tolerance.

Native support for redundant communication interface modules deployment, automatic seamless master-slave switching during bus link failure, zero data interruption for process control signals.

Complete high-integrity system design, built-in power voting diode, fuse overcurrent protection and reverse power supply anti-reverse connection circuit on the baseplate, stable power supply for

bus logic board.

Full online maintainability, realize non-stop CPU replacement and module hot swap, avoid long-term system shutdown loss in continuous production process industries such as chemical industry

and power plant.

Standard complete kit configuration, equipped with base, interconnection cable and terminal resistor, no additional accessories purchase required, convenient for on-site rapid assembly and redundant

rack wiring.

Hardware-level bus signal driving and isolation circuit, strong anti-electromagnetic interference ability, adapt to harsh workshop environment with frequency converter and large motor harmonic

 interference.

Perfect matching with ABB Control Builder M configuration software, no special program modification needed after replacement, only simple bus segment parameter setting required.

Rugged industrial aluminum casing and wide temperature adaptive design, long-term stable 24/7 uninterrupted operation in high-temperature central control room and offshore salt fog corrosive

environment.
