ABB CI855K01 MB300 Master‑Bus300 Communication‑Interface Module (3BSE018106R1)

Product Description

CI855K01 (3BSE018106R1) is a dedicated plug‑in MB300 gateway communication module for the ABB AC 800M controller, connected to the rack back‑plane through the CEX‑Bus.

It adopts the MasterBus‑300 protocol to realize data interconnection between the new‑generation System800xA AC800M system and old‑style Advant Controller 400, MasterPiece200/1 legacy

DCS equipment. Equipped with high‑density 15‑pin D‑sub connector, it supports network redundancy, clock synchronization and hot‑swap maintenance, widely deployed inside chemical‑plant,

thermal‑power, water‑treatment and metallurgy hybrid‑upgrade automation cabinets.

Technical Specifications

Full Model: CI855K01, Part‑number 3BSE018106R1

Brand: ABB, Origin: Sweden‑Estonia

Compatible Control Platform: ABB AC 800M Controller, System 800xA DCS

Backplane Bus: CEX‑Bus controller expansion bus

Communication Protocol: MasterBus 300 (MB300)

Communication Speed: 10 Mbit/s transmission rate

External Connector: 15‑pin high‑density D‑Sub port

Required Base Unit: Matching TP853 terminal baseplate

Power‑supply Consumption: 1.1A @5 VDC from rack back‑plane

Redundancy Function: Supports redundant communication link and redundant CPU

Hot‑Swap: Hot‑pluggable without shutting down the whole control rack

Operating‑Temperature: ‑20℃ ~ +60℃

Storage‑Temperature: ‑40℃ ~ +85℃

Ambient Humidity:5%–95% non‑condensing industrial environment

Installation: Standard DIN‑rail and controller‑rack slot‑in mounting

Module Slot Occupation: Occupies 2 CEX‑Bus slots

Net Weight: Approx.0.55 kg

Certifications: CE, UL, RoHS‑compliant, industrial EMC certification

Key Features

Special‑purpose MB300 gateway for seamless communication between new‑type AC800M and old Advant DCS hardware.

10 Mbps high‑speed MasterBus300 data transmission and dataset‑based cyclic‑communication.

Supports communication‑link redundancy and system clock synchronous function.

Hot‑swap design, enabling online replacement during system running‑time.

High‑density D‑Sub connector delivers stable field‑wiring connection performance.

Works cooperatively with TP853 baseplate for convenient DIN‑rail installation.

Compact rack‑mount structure, saves installation space inside the control cabinet.

Reliable hardware‑isolation circuit shields interference from complicated power‑plant industrial‑site environments.
