Motorola MVME2400 PowerPC 6U VME‑Bus Single‑Board Computer

Product Description

MVME2400 is a 6U‑size VMEbus single‑board computer manufactured by Motorola (Emerson Network Power). Equipped with PowerPC 604e processor,

onboard DRAM and flash memory, it serves as the main CPU controller for VME‑bus‑based industrial control, data acquisition and test‑measurement systems. It follows VME64 bus

specification and provides rich peripheral interfaces including Ethernet, serial ports and SCSI storage. Widely deployed in semiconductor test equipment, aerospace test stands, telecom

switching racks and legacy power‑plant control systems.3. Technical Specifications

Full Model: MVME2400

Brand: Motorola (Emerson), Origin: United‑States

Product Series: MVME2400 VME SBC series

Central Processor: PowerPC 604e, 300‑400 MHz

On‑board Memory: Up to 512 MB ECC DRAM, 8 MB flash ROM

Bus Standard: VME64 (A16/A24/A32/A40 addressing, D16/D32/D64 data)

Ethernet Interface: 10/100 Base‑TX Ethernet port

Serial Ports: Dual RS232 serial channels

Storage Interface: SCSI‑2 / Fast‑Wide SCSI controller

Expansion Interface: PMC / IP module expansion sites

Board Size: Standard 6U VME form‑factor (233 × 160 mm)

Power Supply: +5 VDC from VME backplane, typical 12 W consumption

Operating‑Temperature: 0℃ ~ +55℃

Storage‑Temperature: ‑40℃ ~ +85℃

Ambient Humidity: 5%–95% non‑condensing industrial‑grade

Net Weight: Approx. 0.55 kg

Certifications: CE, UL, RoHS‑compliant, industrial EMC certification

Key Features

High‑performance PowerPC 604e processor delivers strong real‑time computation for industrial control tasks

VME64 high‑speed backplane communication with full compatibility for legacy VMEbus chassis

ECC memory configuration reduces data‑error risks in high‑reliability applications

Integrated Ethernet, SCSI and dual serial ports satisfy networking, storage and debugging demands

PMC / IP expansion sites enable flexible custom I/O function upgrades

Single‑slot 6U compact structure saves limited VME rack slot space

Firmware stored in flash memory supports on‑site BIOS / bootloader upgrade

Rugged hardware design resists vibration and electromagnetic interference in industrial environments
