ABB PFCL201C 3BSE027070R20 20kN Pressductor PillowBlock Vertical Load Cell

Product Description

PFCL201C (3BSE027070R20) is ABB Pressductor pillow‑block type vertical force load cell, adopting patented magneto‑elastic sensing principle, installed under roll bearing housing for strip

vertical‑force and web‑tension measurement. Machined from one‑piece stainless steel, it delivers stable tension feedback for rolling mills, galvanizing lines, pickling lines and continuous strip

processing lines. Equipped with cannon plug‑in connector for field cable connection, factory pre‑calibrated and temperature compensated, widely used in metallurgy, steel‑processing and

paper‑making production lines.

Technical SpecificationsFull Model: PFCL201C Order Code: 3BSE027070R20 Brand: ABB, Origin: Sweden Rated Measuring Load: 20 kN Extended Load: 30 kN Permitted Transverse Load: 10 kN Max Overload Capacity: 200 kN (10 times nominal load)ABB Group Sensing Technology: Pressductor magneto‑elastic effect Measurement Direction: Vertical force Housing Material: Solid stainless steel Connector Type: Cannon plug‑in connector (PFCL201C version) Accuracy Class: ±0.5% FS Repeatability Error: ＜±0.05% Hysteresis: ＜0.2% FS Protection Grade: IP67 Operating Temperature: ‑10℃ ~ +90℃ Compensated Temperature Range: +20℃ ~ +80℃ Storage‑Temperature: ‑40℃ ~ +90℃ Dimension: 220 mm × 125 mm × 50 mm Certifications: CE, industrial EMC certification

Key FeaturesPressductor magneto‑elastic principle, no strain‑gauge structure, excellent anti‑overload performance One‑piece stainless‑steel body, shock‑resistant, corrosion‑resistant, suitable for harsh metallurgical workshop environment Factory pre‑calibrated & temperature compensated, ready‑to‑use after installation Cannon plug‑in connector design, convenient for on‑site cable disassembly and maintenance Specialized for installation beneath roller bearing housing for vertical‑force tension monitoring High‑stability signal output, compatible with ABB PFTL / PFCL measuring units and 800xA DCS system Compact pillow‑block structure, easy mechanical mounting with standard screw holes Long‑term stable operation for continuous steel strip, galvanizing and pickling production lines
