GE IS200HSLAH2ADE HSLA High-Speed Serial Link Interface Board for Mark VI Turbine Control System

GE IS200HSLAH2ADE (abbreviated HSLA) is a dedicated high-speed serial link communication interface board belonging to GE IS200 series hardware, specially designed for

GE Speedtronic Mark VI gas/steam turbine triple modular redundant (TMR) control system. It adopts GE proprietary HSSL (High Speed Serial Link) bus protocol, acting as a high-speed data

bridge between main processor boards (such as IS215UCVEM series CPU) and remote I/O racks, auxiliary control sub-boards and signal conditioning modules inside the turbine cabinet.

This board realizes real-time bidirectional high-speed transmission of turbine speed feedback, valve position signals, interlock logic commands, fault diagnosis data and protection trip signals,

ensuring low-latency synchronous data interaction for three redundant control channels. It integrates signal isolation, line driving, error checking and packet retransmission mechanisms to

resist strong electromagnetic interference inside turbine halls, effectively preventing communication packet loss, data deviation and channel disconnection faults. With conformal coated PCB

design and compact plug-in structure, it is an essential maintenance spare part for cabinet overhaul, communication fault troubleshooting and aging hardware replacement of thermal power

combined-cycle unit turbine control systems worldwide.

Technical Specifications

Part Number: IS200HSLAH2ADE

Manufacturer: General Electric (GE), Origin: USA

Functional Definition: HSLA High Speed Serial Link Interface Board

Compatible System: GE Speedtronic Mark VI TMR Turbine Control System

Communication Bus: GE proprietary HSSL high-speed serial link protocol

Data Transmission Mode: Differential signal transmission with anti-interference design

Backplane Interface: Matches Mark VI standard rack backplane pin definition

PCB Treatment: Conformal coating for moisture, dust, vibration and EMI resistance

Power Supply: Supplied via internal rack backplane DC power

Installation Form: Small plug-in daughter board, internal stacking installation inside main control card assembly

Operating Temperature: -30℃ ~ +65℃

Ambient Humidity: 5%–95% Non-Condensing

Protection Class: IP20 (Internal cabinet installation only)

Net Weight: Approx. 0.3kg

Mechanical Dimension: Custom compact size matching Mark VI controller internal layout

Key Features

Professional HSSL dedicated communication design, ultra-low transmission delay to meet real-time closed-loop control requirements of turbine regulation and protection logic.

Differential signal driving + data checksum verification mechanism, greatly resisting high-frequency electromagnetic interference from high-power thyristor and actuator cabinets.

Three-channel TMR system matching design, supporting synchronous data interaction among three redundant control lanes to guarantee system fault-tolerant operation.

Built-in link fault diagnosis function, automatically identifying open circuit, short circuit and communication timeout faults, feeding alarm information back to main CPU for fault recording.

Stackable daughterboard structure, compact internal installation without occupying independent rack slots, optimizing cabinet space layout.

Pin-to-pin compatibility with HSLA series variant boards, direct plug-and-play replacement during maintenance without program modification or wiring adjustment.

Industrial-grade long-life component selection, adapting long-term continuous running working conditions of power plant turbine control cabinets.

Complete upstream and downstream data forwarding capability, realizing seamless data exchange between main controller and distributed I/O sub-modules.
