YOKOGAWA NFCP501/502 High Performance CPU Module for STARDOM FCN-500 Controller

Product Description

NFCP501 and NFCP502 are core processor modules of Yokogawa STARDOM FCN-500 field control node, responsible for real-time PID regulation, logic interlock, batch control and distributed I/O scheduling.

NFCP501: 2×Gigabit Ethernet ports, standard single/dual redundant CPU

NFCP502: 4×Gigabit Ethernet ports, support independent network isolation (control network + maintenance network)

Fanless low-power design with ECC error-correcting memory, supports CPU hot backup and online hot swap, compatible with CENTUM VP DCS, ProSafe-RS safety system and Modbus TCP/DNP3 third-party equipment, widely used in chemical, power and oil & gas distributed control cabinets as key maintenance spare parts.

Technical Specifications

PN: NFCP501 (2GE) / NFCP502 (4GE), Manufacturer: Yokogawa, Singapore

Processor: High-speed real-time dual-core industrial CPU

Memory: ECC RAM + onboard Flash, SD card for program backup

Network: NFCP501=2×1Gbps RJ45; NFCP502=4×1Gbps RJ45

Interface: RS232 debug serial port, SD card slot, front panel status LEDs

Redundancy: 1:1 master-standby bumpless switchover, hot-swappable

Mount: NFBU series rack base, occupies 2 slots

Operating Temp: -20℃ ~ +70℃, IP20 cabinet installation

Dimension: 65.8×130×149.3mm, fanless convection cooling

Configuration Software: FAST/TOOLS, STARDOM Engineering Tool

Key Features

NFCP502 four gigabit ports realize physical isolation of control and management networks.

ECC memory error correction ensures stable long-cycle process control.

Complete CPU, power, communication triple redundant architecture for zero downtime.

Fanless solid-state design eliminates fan failure risk for 24/7 continuous operation.

SD card one-click program cloning, fast on-site replacement debugging.

Rich industrial protocols connect DCS, safety systems and third-party instruments.

Front LED indicators quickly locate power, run, network and fault status.

Supports E2 bus expansion, up to 8 remote I/O extension racks for large-scale systems.

Application Scope

Distributed control CPU for petrochemical reactor, pipeline and refining unit FCN-500 stations

Thermal power plant boiler, auxiliary water supply, desulfurization process autonomous controller

Oil & gas station, offshore platform RTU and field process control core module

Metallurgy, cement, pharmaceutical batch production line logic & PID control unit

Interconnection gateway between Yokogawa CENTUM VP DCS and field remote equipment

Global STARDOM FCN-500 system overhaul, spare inventory and control network upgrade
