| Basic Information | - Manufacturer: ABB.
- Product Line: Part of ABB’s excitation control portfolio, compatible with large synchronous generators (typically 10MW and above).
- Primary Purpose: Voltage regulation, reactive power control, and protection of generator excitation systems. |
| Electrical Characteristics | - Operating Voltage: Typically 24V DC (control circuit) with compatibility for field voltage up to 500V DC (varies by generator rating).
- Power Consumption: Low-power design to minimize energy loss in excitation loops.
- Output Current: Configurable to match generator field requirements (adjustable via software). |
| Control & Regulation | - Voltage Regulation Accuracy: ±0.2% of rated voltage (steady-state), ensuring stable grid integration.
- Reactive Power Control: Supports both manual and automatic (VAR/PF) modes, enabling precise reactive power sharing in parallel generator setups.
- Response Time: Fast transient response (<100ms) to voltage fluctuations, critical for grid stability during load changes. |
| Protection Features | - Built-in safeguards: Overcurrent protection (field and excitation circuit), overvoltage/undervoltage protection, field winding overheating protection, and loss-of-field detection.
- Fault Diagnostics: Real-time monitoring with error logging and alarm outputs (dry contacts or digital signals) for quick troubleshooting. |
| Communication & Integration | - Interfaces: Supports industry-standard protocols (e.g., Modbus RTU/TCP, Profibus) for communication with SCADA, DCS, or generator control systems.
- Compatibility: Integrates with ABB’s UNITROL® excitation systems and third-party generator management platforms. |
| Environmental Ratings | - Operating Temperature: -10°C to +55°C (industrial grade).
- Humidity: 5% to 95% (non-condensing), suitable for power plant environments.
- Vibration Resistance: Compliant with IEC 60068-2-6 for mechanical durability. |
