GE

GE DS200FCSAG2A | Current sensing interface card

Brand: GE

Model: GE DS200FCSAG2A | Current sensing interface card

Origin: Switzerland

Warranty: 365 days

Quality: new/second-hand

Delivery method: express delivery

Telephone ：+86 18020721390

WeChat：+86 18020721390Email：sakyzeng@foxmail.com

product details

GE DS200FCSAG2A: Current Sensing Interface Card

1. Core Function and Positioning

The GE DS200FCSAG2A is a current sensing interface card designed for GE’s Speedtronic control systems, particularly the Mark V platform—a triple modular redundant (TMR) system used to control steam and gas turbines. As a specialized I/O component, it interfaces with current sensors to monitor and convert current signals into data readable by the turbine control system, enabling precise monitoring of electrical parameters in turbine operations.

2. Key Specifications and Physical Characteristics

Parameter Category	Details
Primary Function	Interfaces with current sensors to measure and transmit current signals within turbine control systems.
System Compatibility	Integrates with GE Speedtronic Mark V systems (TMR architecture) for steam and gas turbine control.
Physical Features	- Compact board with minimal components. - Edge alignment markers and surface grooves for secure mounting. - Four corner drill holes (two conductive holes marked "E1" and "E2" for grounding). - Printed codes: "6DA02" and "6BA02" (likely for assembly or revision tracking).
Component Composition	- Capacitors: 2x Seacor 5.0 10 200V polyester capacitors, 2x small ceramic capacitors, 2x electrolytic capacitors. - Diodes: 8 sets (2 diodes per set, 16 total), arranged in a single row. - Resistors: 4 marked resistor positions, with surface conductors used in place of traditional resistors.
Manufacturing Status	No longer actively produced by GE; available through third-party suppliers as refurbished units.

3. Functional Role

Signal Conversion: Translates analog current signals from sensors into digital data for processing by the Mark V control system, supporting real-time monitoring of turbine electrical loads and performance.
System Integration: Acts as a bridge between current transducers and the main control logic, ensuring accurate data flow in TMR configurations to maintain reliability in critical turbine operations.

4. Application Scenarios

Turbine Control Systems: Used exclusively in GE Speedtronic Mark V systems for gas and steam turbines in power generation, oil refineries, and industrial facilities.
Critical Monitoring: Enables tracking of current levels in turbine subsystems (e.g., generators, auxiliary motors) to prevent overloads and ensure safe operation.

5. Documentation and Resources

Official Data Sheets: No public official data sheet is available for DS200FCSAG2A. For technical details, contact GE Power Support or authorized distributors specializing in legacy Speedtronic components.
Legacy Support: Information is often sourced from industrial automation forums, refurbishers, or historical system manuals for Mark V platforms.

GE DS200FCSAG2A.jpg
