LAM 810-102361-222 Chamber Mux Assembly Electrostatic Chuck Control Interface Module

LAM 810-102361-222 is a factory-original Chamber Mux integrated assembly exclusively designed for Lam Research 2300 series semiconductor plasma etching process equipment.

It is installed directly at the bottom of the reaction chamber electrostatic chuck (ESC), serving as the core electrical and gas distribution switching hub inside the vacuum chamber.

This integrated unit integrates precision printed circuit board, gas solenoid valve distribution pipeline, pin lift drive interface, purge gas switching circuit, temperature sensing

signal acquisition and high-voltage ESC power isolation circuit. It executes real-time switching of process gas paths, vertical motion control of wafer lift pins, real-time collection of chuck

temperature feedback signals, transmission of electrostatic chuck high-voltage adsorption control signals, and gas purge protection for chamber internal components during etching recipes execution.

It ensures highly consistent gas flow distribution, stable wafer clamping force and precise lift pin movement throughout multi-step wafer etching processes, directly determining wafer etching uniformity,

process repeatability and production yield. It is an indispensable critical maintenance spare part for chamber overhaul, fault troubleshooting and component replacement on advanced

wafer fabrication etching production lines.

Technical Specifications

Part Number: 810-102361-222

Manufacturer: Lam Research (USA)

Official Name: Chamber Mux Assembly

Matching Equipment: Lam Research 2300 Series Plasma Etch Processing Platform

Core Functions: Gas path multiplex switching, ESC high-voltage signal routing, lift pin drive control, temperature sensor signal acquisition, chamber purge gas distribution

Structure Composition: Custom circular PCB control board + integrated gas manifold assembly + sealed pneumatic valve group + signal isolation terminal interface

Working Environment: High-vacuum chamber internal environment, corrosive process gas tolerance

Isolation Design: High-voltage isolation circuit for electrostatic chuck anti-breakdown protection

Signal Interface: Multi-channel analog sensing input, digital valve control output, high-voltage power transmission terminals

Process Compatibility: Matches dielectric etch, conductor etch, silicon deep trench etching recipes

Overall Dimension: Custom circular form factor matching 2300 chamber ESC installation dimension

Net Weight: Approx. 2.1kg

Operating Temperature: 5°C ~ 60°C (chamber ambient)

Humidity: Non-condensing vacuum environment

Protection Design: Hermetic gas path sealing, anti-corrosion surface coating, conformal coated PCB for plasma & chemical resistance

Origin: United States

Certification: Semiconductor industry SEMI compliance standard

Key Features

Integrated gas multiplexer + electrical control integrated design, centralized management of chamber gas paths, lift pin motion and ESC electrostatic control to simplify internal chamber wiring and piping layout.

Precision gas path switching structure with high airtight sealing performance, preventing process gas leakage and cross-contamination between different reaction gas pipelines.

Built-in high-voltage isolation and surge suppression circuit, effectively protecting electrostatic chuck from voltage impact damage and improving long-term operational stability of wafer clamping system.

Real-time multi-point temperature signal acquisition function, feeding chuck temperature data back to host control system for closed-loop temperature regulation to guarantee etching uniformity across wafer surface.

Sealed corrosion-resistant structure adapted to corrosive fluorine-based, chlorine-based etching process gases, resisting chemical erosion and plasma degradation inside vacuum chamber.

Modular integrated assembly design, integral disassembly and replacement during chamber maintenance, greatly shortening equipment downtime for overhaul and troubleshooting.

Onboard diagnostic signal terminals for fast on-site troubleshooting of gas path blockage, valve actuation failure, signal disconnection and ESC control abnormal faults.

Fully original mechanical and electrical compatibility with Lam 2300 series chamber configuration, no modification required for direct plug-and-play replacement.

Application Scope

Core chamber internal assembly for Lam Research 2300 series dielectric & conductive plasma etching semiconductor equipment

Wafer production line electrostatic chuck (ESC) gas distribution and control system maintenance replacement spare

Advanced chip manufacturing front-end process etching chamber routine overhaul, preventive spare part inventory backup

Fault repair for abnormal wafer clamping, lift pin jamming, gas switching error, etching uniformity deviation failures

Semiconductor fab equipment retrofit, capacity expansion and second-hand etching tool refurbishment matching component
