Kontron CP307 3U CompactPCI Industrial Single Board Computer

Product Description

CP307 is Kontron 3U CompactPCI single board computer for industrial control and test systems.

It equips industrial Intel processor, onboard memory, dual Ethernet and multiple serial/USB interfaces, supports hot swap and wide range DC power input. Conformal coated PCB

and reinforced anti-vibration design, standard rack installation, widely used as replacement spare for railway, measurement and automation control racks.

Technical Specifications

Model: CP307, Brand: Kontron, Origin: Germany

Form Factor: 3U CompactPCI standard board

Processor: Embedded Intel industrial CPU

Onboard Memory: SODIMM DDR industrial memory

Communication Interfaces

Dual Gigabit Ethernet ports

RS232/422 serial ports, USB 2.0 host ports

Storage: Onboard SATA interface for SSD/HDD

Power Supply: Wide range 12–36VDC industrial power

Hot Swap: CompactPCI hot-swap function supported

Operating Temperature: -40℃ ~ +70℃ full load

Storage Temperature: -40℃ ~ +85℃

Humidity: 5%–95% non-condensing, conformal coated PCB

Protection Class: IP20 cabinet installation only

Mounting: Standard CompactPCI rack slot plug-in

Net Weight: Approx. 0.38kg

Certifications: CE, EN50155 railway standard, UL industrial compliance

Key Features

Standard 3U CompactPCI form factor, compatible with universal industrial CompactPCI rack systems.

Wide temperature grade hardware supports stable operation under extreme cold and hot workshop environments.

Dual independent Gigabit Ethernet separates control and data transmission channels to avoid single network failure.

Multiple serial and USB interfaces connect field sensors, touch screens and peripheral test equipment.

CompactPCI hot-swap design allows board replacement without powering off the whole system.

Onboard SATA storage interface supports industrial SSD for shock-resistant data recording.

Full anti-vibration reinforced layout and conformal coated PCB fit railway and mobile test equipment.

Compact size low power consumption, reliable 24/7 continuous operation for embedded industrial control systems.
