ABB PP826 3BSE042244R1 6.5-inch Panel800 Touch HMI Panel

Product Description

PP826 (3BSE042244R1) belongs to ABB Panel800 series compact operator panel, matched with AC800M and System 800xA DCS.

It adopts 6.5-inch VGA TFT color resistive touch screen with physical function keys, integrates Ethernet, RS232/485 and USB ports, supports Modbus TCP and ABB proprietary protocols.

Front IP65 dustproof splash-proof, conformal coated circuit, cabinet embedded installation, widely used as replacement spare for power, chemical and water treatment control rooms.

Technical Specifications

Model: PP826, Material No.: 3BSE042244R1

Brand: ABB, Origin: Switzerland

Display: 6.5-inch TFT LCD, 640×480 VGA, 64k colors

Touch Type: Resistive touch, support glove operation

Operation Keys: Customized membrane function keys + numeric keypad

Communication Interfaces

RJ45 Ethernet port

RS232 / RS485 serial terminals

USB host port for program upload and data export

Supported Protocols: Modbus TCP, Modbus RTU, ABB control bus

Power Supply: 18–32VDC nominal 24VDC

Operating Temperature: 0℃ ~ +60℃ full load

Storage Temperature: -40℃ ~ +70℃

Humidity: 5%–95% non-condensing, conformal coated PCB

Protection Grade: Front IP65, rear IP20

Mounting: Cabinet door embedded mounting

Net Weight: Approx. 2kg

Certifications: CE, UL industrial compliance

Key Features

Compact 6.5-inch touch screen with physical keys, convenient for operators to adjust parameters and check alarms on site.

Complete communication interfaces realize stable data interaction with AC800M CPU and third-party PLC instruments.

Local storage records process trends, alarm logs and batch recipes, exportable via USB without extra PC software.

Front IP65 protection resists workshop dust, water splash and cleaning liquid corrosion.

Resistive touch supports operation with gloves, suitable for multi-dust and multi-oil industrial sites.

Fully compatible with System 800xA and AC800M control systems for seamless DCS monitoring.

Aluminum alloy front frame, easy one-to-one replacement for old PP826 panels on control cabinet doors.

Anti-vibration conformal coated PCB, stable 24/7 continuous operation in humid central control rooms.
