ABB SCYC55830 58063282A Tachometer Speed Signal Converter Terminal Board

Product Description

SCYC55830 with part code 58063282A is dedicated speed signal conversion board for ABB high-power drive systems.

It converts MPU tachometer pulse signals into standard digital signals for motor closed-loop speed feedback, supports frequency up to 20kHz with high measuring accuracy.

Equipped with multi-channel signal terminals and backplane bus connector, all signal circuits with galvanic isolation, conformal coated PCB, rack plug-in installation,

core replacement spare for metallurgy, paper and power plant large motor drive cabinets.

Technical Specifications

Model: SCYC55830, Material Code: 58063282A

Brand: ABB, Origin: Switzerland

Function: Tacho pulse signal acquisition & conversion for motor speed feedback

Input Frequency Range: 0–20kHz tachometer signal

Measuring Accuracy: ±0.2% full scale

Input Signal: MPU magnetic pickup pulse signal

Power Supply: 24VDC rack backplane power supply

Power Consumption: Approx. 0.2W

Operating Temperature: -20℃ ~ +60℃ full load

Storage Temperature: -40℃ ~ +85℃

Humidity: 5%–95% non-condensing, conformal coated PCB

Protection Class: IP20 cabinet installation only

Mounting: Standard single slot plug-in rack mounting

Net Weight: Approx. 0.55kg

Certifications: CE, UL industrial compliance

Key Features

Specialized tacho signal processing board, delivers stable high-precision speed feedback for large AC/DC motor closed-loop control.

Wide 0–20kHz frequency input range adapts to low and high speed motor MPU pickup sensors.

Full galvanic isolation for all input channels eliminates ground loop interference and pulse signal distortion.

Multi-terminal signal wiring design simplifies on-site tachometer sensor wiring layout and maintenance.

Front indicator LEDs display signal input status for quick judgment of sensor and wiring faults.

Standard rack plug-in structure supports direct one-to-one replacement without complicated wiring modification.

Anti-corrosion coated PCB resists dust, humidity and vibration in heavy industry drive control rooms.

Ultra-stable signal conversion ensures motor speed steady regulation and avoids speed fluctuation during load changes.
