GE IS200DTAIH1ABB Mark‑VI Analog I/O Terminal Circuit‑Board

Product Description

Technical Specifications

• Full Model: IS200DTAIH1ABB
• Brand: GE General‑Electric, Origin: United‑States
• Applicable Control Platform: Mark‑VI Speedtronic Turbine‑Control System
• Analogue Input: 10‑channel universal analog signal acquisition
• Analogue Output: 2‑channel configurable current‑output, 0‑20mA / 0‑200mA adjusted via onboard jumpers
• Back‑plane Connector: 37‑pin JR1 locking‑type connector
• Field‑wiring Terminal: TB1 48‑pin screw terminal strip
• Configuration Hardware: Total 21‑piece jumper switches for signal‑range setup
• Installation Method: Plastic‑bracket supported DIN‑rail mounting
• Rack‑supply Voltage: +5 VDC back‑plane power supply
• Operating‑Temperature: ‑20℃ ~ +60℃
• Storage‑Temperature: ‑40℃ ~ +85℃
• Ambient Humidity:5%–95% non‑condensing industrial environment
• Net Weight: Approx.0.45 kg
• Certifications: CE, UL, RoHS‑compliant, power‑industry EMC certification

Key Features

1. 10‑way analog‑input and dual‑channel analog‑output meets multi‑parameter turbine‑signal collection demands.
2. Jumper‑selectable 0‑20mA or 0‑200mA output range adapts to various‑type field transmitters.
3. Integrated 48‑screw terminal block supports shielded‑twisted‑pair field wiring and dedicated earth‑connection terminal.
4. Compact DIN‑rail bracket structure enables flexible cabinet installation layout.
5. Stable 37‑pin locking‑type connector guarantees vibration‑resistant connection with Mark‑VI main rack.
6. Multiple‑jumpers allow fast on‑site signal‑type configuration without software modification.
7. Built‑in signal‑filter circuits to cut down electromagnetic interference from power‑plant environments.
8. Standard‑size PCB fits well with the whole Mark‑VI series turbine‑control hardware ecosystem.
