DIGITAL POWER CPCI-AC-6U-500 900-7002-99 Communication input power module

Data Sheet (Specific Parameters)

• Input Characteristics
• Input Voltage Range: 85-264V AC (auto-ranging), single-phase1.
• Input Frequency: 47-435Hz1.
• Inrush Current: Max 50A at 230V AC1.
• Power Factor: 0.98 typical at 230V AC full load, 0.99 typical at 115V AC full load1.
• Input Protection: Built-in IEC-type 10A 250V AC slow-blow fuse1.
• Power Failure Hold-up Time: 50ms at 75-300V AC1.
• Output Characteristics
• Output Power: 500W522.
• Output Voltage: Multiple DC outputs compliant with CPCI standards (e.g., +3.3V, +5V, +12V, -12V), specific current parameters refer to official manual614.
• Voltage Regulation: ±0.5% at full load7.
• Load Regulation: ±1.0%-±2.0% at 10%-100% load7.
• Ripple Factor: ≤10% (referenced to similar product standards)818.
• Physical Characteristics
• Dimensions: 6U CompactPCI standard (height ≈105mm), specific length and width not specified212.
• Operating Temperature: 0°C-50°C11.
• Storage Temperature: -20°C-70°C1.
• Protection Level: IP20 (suitable for indoor environments)1.
• Efficiency

• 80% at 230V AC full load, >76% at 120V AC full load1.

Product Performance

• High Reliability: Passes industrial-grade testing with electromagnetic interference resistance, suitable for complex industrial environments118.
• Wide Voltage Adaptability: Supports 85-264V AC input, meeting global grid requirements1.
• Energy Efficiency: Power factor up to 0.98 reduces energy consumption1.
• Multi-Output Design: Provides multiple DC voltages required for CPCI buses to power system components614.
• Stable Output: Voltage and load regulation technologies ensure output stability7.

Application Fields

• Industrial Automation: Powers PLCs, industrial computers, and other equipment318.
• Communication Equipment: Base stations, data centers, and communication systems13.
• Medical Instruments: Surgical devices, medical diagnostic equipment13.
• Transportation: Rail transit signaling systems, vehicle control modules3.

Related Series Products

• CPCI-AC Series: CPCI-AC-6U-400 (400W), CPCI-AC-3U-300 (300W), CPCI-AC-3U-200 (200W)52022.
• CPCI-DC Series: CPCI-DC-6U-500 (500W DC input), CPCI-DC-3U-300 (300W DC input)
