ABB XVC768AE102 3BHB007211R0102
ABB XVC768AE102 3BHB007211R0102
ABB XVC768AE102 3BHB007211R0102
ABB XVC768AE102 3BHB007211R0102

ABB XVC768AE102 3BHB007211R0102 Interface Control Board

Brand: ABB

Model: ABB XVC768AE102 3BHB007211R0102 Interface Control Board

Warranty: 365 days

Quality: new/second-hand

Delivery method: express delivery

Telephone :+86 18020721390

WeChat:+86 18020721390Email:sakyzeng@foxmail.com

product details

Product Overview

ABB XVC768AE102, part number 3BHB007211R0102, is a dedicated interface control board for ABB UNITROL excitation system and MEGADRIVE high-power

converter series. It serves as the communication and signal coordination bridge between the main control unit and the power stack. This board handles command distribution,

status feedback, signal synchronization and fault signal transmission, ensuring coordinated operation of control logic and power units. It is widely used in power plant generator

excitation cabinets and medium-voltage variable frequency drives, and is a critical legacy spare for equipment overhaul and replacement.

XVC768AE102 3BHB007211R0102.何姗姗.20250721 (3).jpg


Technical Specifications

  • Brand: ABB
  • Model: XVC768AE102
  • Part No: 3BHB007211R0102
  • Product Type: Interface Control Board
  • Supply Voltage: 24V DC
  • Operating Temperature: -20℃ ~ +70℃
  • Mounting: Rack plug-in installation
  • Compatible System: ABB UNITROL excitation system, MEGADRIVE converter
  • Status: Discontinued original spare
  • Function: Signal synchronization, command transmission, status & fault feedback
  • Industry: Power generation, metallurgy, heavy industry high-power drive

  • XVC768AE102 3BHB007211R0102.何姗姗.20250721 (2).jpg

Main Features

  1. High-speed synchronous signal interaction between controller and power unit.
  2. Galvanic isolation design to separate low-voltage control and high-voltage power circuits.
  3. Built-in EMI filter to resist strong electromagnetic interference in converter cabinets.
  4. Multi-channel fault acquisition for overvoltage, overcurrent and temperature alarms.
  5. Standard plug-in PCB layout for quick on-site replacement during maintenance.
  6. Continuous hardware self-diagnosis with fault signal upload to master control.
  7. Mature stable design, fit for 24/7 continuous operation of excitation and drive equipment.

  8. XVC768AE102 3BHB007211R0102.何姗姗.20240129_171401 (3).jpg

Application Scenarios

  • Power plant UNITROL synchronous generator excitation control cabinet
  • ABB MEGADRIVE medium & high voltage frequency converter control unit
  • Metallurgical rolling mill large synchronous motor drive system
  • High-power rectifier and inverter cabinet signal coordination
  • Legacy excitation and converter system spare replacement and repair project

  • XVC768AE102 3BHB007211R0102.何姗姗.20240129_171401 (2).jpg
