GE VMIVME-7807RC | high-performance single board computer

GE VMIVME-7807RC is a highly flexible and high-performance single board computer suitable for I/O-intensive applications

· Processor: Intel Pentium M processor is used, with three frequency options of 1.1GHz, 1.6GHz, and 1.8GHz. 1.1GHz and 1.6GHz processors have 1M bytes of L2 cache,

while 1.8GHz processors have 2M bytes of L2 cache.

· Memory: Supports DDR SDRAM, optional ECC support, maximum storage capacity of 1.5Gbyte, SDRAM with dual ports of VMEbus.

· Expansion slot: 1 PCI-X, 66MHz PMC expansion slot.

· Ethernet: Dual Gigabit Ethernet controller (Intel 82546GB), supporting 10BaseT, 100BaseTX, and 1000BaseT interfaces, with optional Vita 31.1 support.

· Other interfaces: Four asynchronous 16550 compatible serial ports, four Universal Serial Bus (USB) 2.0 connections, two on the front panel and two on the back I/O;

Internal SVGA and DVI controllers, supporting serial ATA through P2 backend I/O and 400MHz system bus via Intel 855GME chipset.

· Non volatile storage: 32KB non-volatile SRAM.

· Size: 203 * 260 * 65MM.
