GE IS215VPROH1B VPRO Independent Emergency Turbine Protection Module for Mark VI Control System

Product Description

GE IS215VPROH1B (VPRO) is a standalone triple redundant safety board for GE Mark VI turbine rack, independent of main control CPU to execute emergency protection logic.

It monitors turbine speed deviation, overspeed, temperature analog signals, implements backup synchronization check and emergency trip logic, driving trip solenoids via TREG terminal board.

Equipped with 10Base2 IONet BNC communication and RS232 debug port, adopts stacked double-layer PCB with heat sink design, triple VPRO voting architecture eliminates single-point failure,

core safety spare for power plant gas/steam turbine control cabinets.

Technical Specifications

PN: IS215VPROH1B, Manufacturer: GE USA

Form Factor: 6U VME stacked dual PCB assembly

CPU: 300MHz AMD Elan SC520

Communication: 1×BNC 10Mbps IONet, DB9 RS232 debug

Redundancy: Triple VPRO module voting safety logic

Trip Output: Matches TREG/TRPG trip solenoid terminals

Power: 24VDC rack backplane supply

Operating Temp: -30℃ ~ +65℃; IP20 cabinet installation

Dimension: 263×138×88mm, weight ~2.35kg

Indicator: Front panel LED for power, run, fault, trip status

Key Features

Independent safety logic, separated from main controller to avoid total system failure risk.

Triple modular redundant voting design, reliable overspeed emergency trip protection.

Built-in speed difference detection, backup synch check and thermocouple signal acquisition.

IONet bus realizes data interaction with Mark VI main control rack.

Large aluminum heat sink ensures stable long-term continuous operation.

Full self-diagnosis detects circuit short, open circuit and communication failure.

Standard VME rack plug-in, direct replacement for maintenance overhaul.

Controls multi-channel trip solenoids to realize turbine fast emergency shutdown.

Application Scope

Independent overspeed safety protection unit for Frame series gas turbine Mark VI cabinets

Steam turbine, generator emergency trip control core board in thermal power plants

Cogeneration unit, industrial large compressor safety interlock protection module

Offshore platform power generation turbine safety instrument system spare replacement

Global aging Mark VI turbine control cabinet maintenance, spare inventory and safety upgrade
