GE IC687BEM713 Genius Bus Interface Module for GE Series 90-70 PLC Controller Rack

Product Description

GR IC687BEM713 is a dedicated Genius bus master communication module for GE Series 90-70 PLC system. It acts as a bridge between CPU backplane and remote Genius distributed I/O

stations, handling real-time data polling, signal mapping and fault diagnostics of multi-drop Genius field bus. Each module supports one independent Genius bus trunk, connects up to 32 Genius

I/O blocks over twisted pair wiring, supports dual bus cable redundancy for uninterrupted field signal collection. Standard single-slot rack plug-in design, powered by rack backplane, widely used

as maintenance spare for power, water treatment, manufacturing old GE PLC control cabinets.

Technical Specifications

PN: IC687BEM713, Manufacturer: GE Fanuc USA

Compatible System: GE Series 90-70 PLC CPU rack

Bus Type: GE Genius Serial Field Bus

Maximum Nodes: 32 Genius I/O stations per module

Transmission Medium: Shielded twisted pair cable

Communication Distance: Max 2000 meters (proper cable layout)

Bus Redundancy: Support dual cable redundant bus wiring

Data Refresh Speed: Fast deterministic cycle for discrete & analog I/O

Mount: Single slot rack plug-in module, hot-swappable

Power Supply: 5V backplane power, low power consumption

Operating Temperature: 0℃ ~ +60℃; Storage -40℃ ~ +85℃

Humidity: 5%–95% non-condensing, IP20 cabinet installation

Front Panel: LED indicators for power, bus active, fault, channel status

Programming Software: Proficy Machine Edition, Logicmaster 90

Key Features

Independent Genius bus master controller, offloads remote I/O communication tasks from PLC CPU.

Supports up to 32 distributed Genius I/O modules to expand remote field signal collection range.

Dual cable redundant bus function, single cable damage will not cause loss of field signals.

Complete bus self-diagnosis, quickly locate cable short, open circuit, address conflict and station failure.

Single-slot compact design, saves rack space for multi-bus expansion layout.

Seamless matching all Series 90-70 CPU models and full range Genius analog/digital I/O blocks.

Conformal coated PCB option for dusty, high-humidity industrial workshop environments.

Hot-swap online replacement without PLC shutdown, reduce equipment maintenance downtime.

Application Scope

Remote Genius distributed I/O communication gateway for factory production line Series 90-70 PLC racks

Thermal power plant auxiliary water, ash handling, desulfurization PLC remote signal interface module

Sewage treatment, water supply plant distributed flow, level, pressure data acquisition bus card

Metallurgy, cement, chemical batch control system remote field IO expansion spare part

Oil & gas small station auxiliary control cabinet legacy GE PLC communication replacement board

Global aging GE Series 90-70 automation system overhaul, spare inventory and technical transformation
