GE DS200STBAG1 is a product of General Electric (GE), with the full name
Basic Drive Terminal Board for Mark V Speedtronic Control System. The following is a detailed description based on official technical documents and industry data:
It is a dedicated terminal board designed for GE’s Mark V Speedtronic control system, which is widely used in turbine (gas, steam, and wind) control applications. As a critical I/O interface component, it provides centralized connection points for input/output signals, facilitating signal transmission between the turbine control system and external devices (e.g., sensors, actuators, power supplies, and user interfaces). It plays a key role in organizing wiring, simplifying system integration, and supporting on-site configuration and diagnostics in industrial power and energy applications.
- Signal Routing: Centralizes I/O signal distribution, reducing wiring complexity and minimizing signal interference in turbine control systems.
- Customization Options: Includes multiple system-configurable jumpers for adjusting encoder voltage, signal polarity, and interface compatibility to meet specific application needs.
- Diagnostic Support: Serves as a user interface hub for on-site troubleshooting, enabling access to system status, error codes, and configuration parameters via the serial port.
- Protection Integration: Integrates passive interface circuits to buffer and protect sensitive control signals from voltage spikes or noise in industrial environments.
![]()
