TMEIC ARND-3110J DSP Main Control

Product Description

ARND-3110J is a core DSP main computing control board manufactured by TMEIC Japan, belonging to TMdrive-MVe2 medium voltage high-power inverter dedicated controller series.

It is specially matched with TMdrive large medium voltage frequency converters, receiving analog sampling signals and upper system operation commands from DCS/SIS, realizing vector

closed-loop speed and torque regulation of high-voltage motors, PWM drive pulse output for power modules, and full-set electrical fault protection logic execution. The board collects voltage,

current and temperature feedback signals, outputs isolated dry contact switch signals for interlock control of bypass cabinets, cooling fans and contactors, completes overload, overvoltage,

overcurrent, overheating and IGBT fault protection functions.

Adopts rack slot plug-in structure, front panel LED running and fault status indicators, PCB with three-proof conformal coating, standard internal cabinet subrack installation. It is a key

vulnerable spare part for thermal power plant boiler fans, circulating water pumps, steel mill rolling main drives, mine belt conveyor medium voltage drive equipment.

Technical Specifications

Model: ARND-3110J, Brand: TMEIC, Origin: Japan

Matched Equipment: TMdrive-MVe2 series medium voltage high-power variable frequency drive

Control Mode: High-precision motor vector closed-loop control algorithm

Power Supply: 24VDC industrial DC power supply (allowable fluctuation range ±20%)

Analog Acquisition: Built-in high-speed DSP processor with 16-bit high-precision ADC chip

Communication Interface: RS485 Modbus RTU, Ethernet TCP/IP, optional Profibus-DP expansion

Anti-Vibration Grade: 5G industrial standard vibration resistance

Operating Ambient Temperature: -10℃ ~ +60℃ continuous long-term operation

Storage Temperature: -40℃ ~ +85℃

Humidity Condition: 5%–95% non-condensing environment, moisture-proof, mildew-proof and salt fog-proof coated circuit board

Protection Class: IP20 (only installed inside electrical control cabinet)

Mounting Way: Eurocard slot plug-in installation on inverter rack, replaceable after power-off

Net Weight: Approx. 0.5kg

Certifications: CE, Class 1 Div 2 hazardous area certification, industrial EMC anti-interference certification

Key Features

Professional high-power medium voltage motor vector control algorithm, achieves stable high-precision torque and rotating speed closed-loop adjustment, improves drive operation stability under

heavy load working conditions.

Comprehensive full coverage hardware continuous self-diagnosis function, real-time monitoring power unit abnormal, module overtemperature, DC bus voltage fault, lock drive output and upload

fault codes to upper DCS system.

Multi-channel optically isolated relay digital output points, effectively resist harmonic EMI interference generated by frequency converters, avoid wrong action of external interlock loops.

Standard rack plug-in modular design, one-to-one direct replacement after power cut without rewiring, greatly shorten on-site maintenance duration and equipment downtime loss.

Multi-protocol communication access capability, seamlessly connected with power plant SIS/DCS control system for remote start-stop instruction reception and operating parameter remote uploading.

Excellent harsh environment adaptability with three-proof coating, stable 24/7 uninterrupted operation in high temperature, dusty and strong electromagnetic interference central control room environment.

Perfect backward compatibility, can be directly replaced by upgraded alternative model ARND-3110K without large-scale program modification and debugging.

Mass mature application in thermal power, metallurgy, mining and cement industries, reliable core control spare part for medium voltage frequency conversion drive system renovation and overhaul.
